Hardware Installation - 30 -
23) IMR_KEY (LSI RAID Key Header)
24) LSI_UART1 (LSI UART Header)
1
1
4
PinNo. Denition
1 KEY
2 GND
PinNo. Denition
1 UART0_TX
2 GND
3 UART0_RX
4 P1V8
