95
Appendix
Gigaset SL910/910A / GBR/IRL / A31008-M2300-L101-1-7619 / appendix.fm / 23.08.2011
Version 4.1, 21.11.2007
General specifications
DECT
Bluetooth
Pin connections on the telephone jack
DECT standard Supported
GAP standard Supported
No. of channels 60 duplex channels
Radio frequency range 1880–1900 MHz
Duplex method Time multiplex, 10 ms frame length
Repeat frequency of the transmission pulse 100 Hz
Length of the transmission pulse 370 μs
Channel grid 1728 kHz
Bit rate 1152 kbit/s
Modulation GFSK
Language code 32 kbit/s
Transmission power 10 mW average power per channel,
250 mW pulse power
Range Up to 300 m outdoors, up to 50 m indoors
Base power supply 230 V ~/50 Hz
Ambient conditions for operation +5°C to +45°C, 20% to 75% relative humidity
Dialling mode DTMF (tone dialling)/PD (pulse dialling)
Radio frequency range 2402–2480 MHz
Transmission power 4 mW pulse power
1unused
2unused
3a
4b
5unused
6unused
