11.5.7 P
_O/P Menu (Proportional Output Control)
This menu controls the analog and digital proportional outputs. There are two outputs, one for distance and
one for amplitude. The outputs are enabled when the gates are triggered and the values are updated with the
PRF frequency.
O/P 1
DIST.10 (Gate1)
DIST.20 (Gate2)
E1–E20 Distance between two depth measurements
ALARM 10 Output voltage when alarm 1 is activated
P/P 2
LEVEL10 (Gate1)
LEVEL20 (Gate2)
L1-L20 difference between two amplitudes
ALARM 20 Output voltage when alarm 2 is activated
CAL
Used to change the voltage on the proportional outputs between 0V and
10.1V
11.5.8 CLOCK Menu
SET OFF
The time and date are not shown on the lower part of the screen
SET TIME
Used to set the time
N.B.: make sure to press SET to save the time changes
HOURS
Used to set the hours (in the 24 hour format)
MINS
Used to set the minutes
SET DATE
Used to set the date (this is selected by pressing the black key next to SET
then
!
N
.B.: make sure to press SET to save the date changes
DATE
Used to set the day
MONTH
Used to set the month
YEAR
Used to set the year
