Procedure for deleting a calibration
F
ollow the previously described procedure but select the DELETE item in the MODE window.
Procedure for adding notes
It is possible to add notes to the calibration using the EDIT NOTE function. By pressing the key adjacent to
the EDIT window you access the related entry screen.
The TYPE line is composed of 8 characters, the OPERATOR, WORK SITE and PROBE lines are composed
of 25 characters while the NOTE line can contain up to 75 characters.
The
a
nd
k
eys are used to move the cursor along the line while the key adjacent to the NEXT window is
used to go to the next line.
To eliminate a character, position the cursor above it and press the key adjacent to the DELETE
CHARACTER box.
To enter a space, position the cursor above it and press the key adjacent to the ENTER CHARACTER box.
To select a map character, use the
and keys to move the cursor above the desired character and press
th
e SET key.
Once all the notes have been entered press the key adjacent to the EXIT box. It is necessary to save the
calibration again to memorize the notes.
11.6.2 A-LOG menu
This menu makes it possible to memorize and recall up to 800 A-Scans with their related settings.
STORE:
Used to select the location of the memory (1-800).
MODE:
RECALL
Used to recall the memorized A-Scans. By pressing the SET key the A-
Scan is recalled, which is displayed in ,(((mode. To remove the recalled
A-Scan press
.
M
ODE:
DELETE
Used to delete a ,$$ memory containing an A-Scan and its related
calibration. Press the SET key to remove it, and press a second time to
confirm.
MODE:
LIST
Shows the notes associated to the memorized A-Scan and calibration
setting. The notes are displayed and by pressing the SET key the memory
is recalled.
MODE:
INDEX
This is the index of all the memories, use the
and keys to scroll the
li
st.
MODE:
STORE
Used to memorize the A-Scan and calibration settings in the location
identified in the MEMOR. box. Press SET once to memorize, and a
second time to confirm.
STATE
Only display.
FULL indicates that the memory location is used and contains data.EMPTY
indicates that the memory location is not used and does not contain any
data.
To go from FULL toEMPTYuse the functionDELETE
EDIT
Used to add notes deemed opportune for identifying the A-Scan.
