79032996 A Rev. 01-45
General Information
Rear Powerfold Ladder
FIG. 104: The optional rear powerfold ladder is designed
to let the operator raise and lower the ladder while
standing on the ground. Using electrical controls, the
ladder can be lowered to gain access to the engine
compartment.
FIG. 105: The powerfold ladder control consists of a
switch (1) located under the rear deck on the right-hand
side of the combine. An electric linear actuator, located on
the rear deck, raises or lowers the ladder when the switch
is activated.
ENGINE
Type of Engine Oil
Lubricating oils must meet the demanding standards for a
turbocharged after cooled engine. The use of quality
lubricating oils along with timely oil and filter changes will
maintain engine durability and performance standards.
Use only AGCO approved oil or oil to American Petroleum
Institute (API) performance classification CI4.
IMPORTANT: Do not use an oil with an API performance
classification lower than CI4.
A limit of 1% by weight sulfated ash content is
recommended to control oil consumption and valve/piston
deposits. Sulfated ash content must never exceed 1.85%
by weight.
IMPORTANT: Non-detergent or straight mineral type
motor oils must not be used.
FIG. 104
M627688
FIG. 105
1
H627011
