10PowerUp Installation and Operation Manual
Installer-supplied Components
The installers should prepare the following parts for the PowerUp charger
installation:
1. Conduit of appropriate size for input power wires to ensure water resistance.
2. Conduit fitting(s) for input power wires to ensure water resistance.
3. Upstream breakers:
To reduce the risk of fire, only connect to a circuit with 60 amperes maxi-
mum branch circuit overcurrent protection in accordance with the National
Electrical Code, ANSI/NFPA 70, and the Canadian Electrical Code, Part 1,
C22.1.
Model Circuit Breaker Specifications
EIAW-U11K 60A max., 208/240V min., 2 poles
