26PowerUp Installation and Operation Manual
SPECIFICATIONS
Item Description
Model Name PowerUp
Model Number EIAW-U11KSSU7E01
AC Input 208/240Vac, 60Hz 48A max.
AC Output 11.5kW max; 48A max.
Charging Outlet SAEJ1772/Type1
Operating Temperature -40 – 122°F (-40 – 50°C)
Storage Temperature -40 – 185°F (-40 – 85°C)
Humidity < 95%, non-condensing
Altitude Up to 4,000m
Enclosure IK08, NEMA 4X, indoor/outdoor installation
Cabling 25’, J1772
Dimension (W x H x D) 8.11 x 13.15 x 3.86 in. (206 x 334 x 98 mm.)
Weight 13.23 lbs. (6 kg.)
Certificates
UL 2594
UL 2231
UL 1998
Energy Star Rated
EMC FCC Part 15, Class B
Network Interface with Backend WiFi6
