GM PowerUp - Recommended Installation Space

13PowerUp Installation and Operation Manual
Recommended Installation Space
Installers should follow applicable accessibility requirements when selecting
the mounting position. The PowerUp charger should be mounted at a height
between 600 mm (24 inches) and 1.2 m (47.2 inches) above ground.
Top View
Front View
19.7”
(500 mm)
7.9”
(200 mm)
24 - 47.2”
(600 - 1200 mm)
19.7”
(500 mm)
19.7”
(500 mm)
19.7”
(500 mm)
19.7”
(500 mm)
