16PowerUp Installation and Operation Manual
3. Use two of the wall screws to mount the bracket onto the wall so that the
hooks on the bracket protrude outwards.
1
2
Note:
A single wall screw installed on the right side of the mount is required, but
installing both screws is recommended.
4. Place the unit on the bracket by aligning the slots on the rear of the chas-
sis to the corresponding hooks on the bracket.
5. Use the remaining screw to secure the unit to the wall.
