GM PowerUp - Page 18

18PowerUp Installation and Operation Manual
L2 L1PE
Location Wire Gauge Torque
L1 / L2 6AWG max 19 ± 2 in-lbs (2.2 ± 0.2 Nm)
PE 6-10AWG 19 ± 2 in-lbs (2.2 ± 0.2 Nm)
Once you have connected the power wires you can proceed with configuring
the DIP switches.
