GLT Ω L IFT
O PERATION AND M AINTENANCE M ANUAL
Page | 54
latches are inserted into the safety contacts.
If there is more than one safety rail: lift the nearest one and continue until
the furthest one is lifted.
7
Close the landing door.
• Visible:RED light
8
Release the emergency stop (red button).
• Visible:GREEN light
9
Turn the selector switch on the maintenance push-button panel to
“maintenance operation”.
• Visible:GREEN light
10
The maintenance technician can now use the buttons on the maintenance
push-button panel to move the car up (by pressing the blue and white
buttons simultaneously) or down (by pressing the blue and black buttons
simultaneously) at speed (automatically selected as slow).
When stopping the movement, it is advisable to release the common blue
button before the direction button so that the lift stops more smoothly
(highly recommended).
• Visible:GREEN light
11
Stop the car with the roof surface level with the landing sill from where
you want to exit at the end of the work and/or inspections (of course, it
may not be the bottom floor for entering the pit).
IMPORTANT!
Nevertheless, there are two safety stop contacts in the headroom; the first upwards one is active
when the lift is in maintenance operation and stops the car moving up when it reaches it.
This contact is positioned to anticipate the impact of the counterweight on the buffer.
EXIT SEQUENCE (ROOF)
STEP
ACTION NOTES
1
Press the emergency stop (red button).
• Visible:RED light
2
Turn the selector switch on the maintenance push-button panel to
“automatic operation”.
• Visible:RED light
3
Lower the EN81-21 safety rails folding them on the car roof and make sure
the latches are inserted into the safety contacts.
If there is more than one safety rail: lower the furthest one and continue
until the one nearest the door is lowered.
• Visible:RED light
4
Open the landing door at the floor where you have decided to exit,
unlocking the lock manually.
• Visible:RED light
5
Climb down from the roof and stand on the landing.
• Visible:RED light
6
Release the emergency stop (red button).
• Visible:RED light
7
Close the landing door.
• Not visible:RED light
IMPORTANT!
When exiting the pit and/or the car roof, the maintenance technician is advised to ensure that no
equipment or tools have been left behind that can impair smooth operation of the lift or even
cause accidents.
