10991793EN
-
19.10.2022
4.0
ENG
GLT
Ω
L
IFT
O
PERATION
M
ANUAL
Page | 55
ENTRY SEQUENCE (PIT) TO RESTORE THE PEDESTALS TO THE UNUSED POSITION
STEP
ACTION NOTES
1
Walk down the building’s stairs to the bottom floor at
the pit.
2
Open the landing door to the pit with the emergency key.
Visible:RED light
Meaning: The maintenance
technician can descend into the pit
safely as he is protected by the A3
anti-creep system of the overspeed
governor, which is active and
directly connected to the safety
system triggered by the intervention
of the car safety gear.
3
The lift is out of service (floor call buttons are lit up).
Visible:RED light
4
Press the emergency stop (red button).
Visible:RED light
5
Detach the ladder from its storage housing and place it ready for descent
into the pit.
Visible:RED light
6
Close the landing door.
Visible:RED light
7
Put the ladder back into its storage housing.
Visible:RED light
8
Lower the “CAR” pedestal from the vertical position to the horizontal
position.
Visible:RED light
9
Lower the “COUNTERWEIGHTpedestal from the vertical position to the
horizontal position.
Visible:RED light
EXIT SEQUENCE (PIT)
STEP
ACTION NOTES
1
Detach the ladder from its storage housing and place it ready to climb out
of the pit.
Visible:RED light
2
Open the landing door to the pit by pulling the lock release cable on the
door.
Visible:RED light
3
Climb out of the pit up to the entrance landing.
Visible:RED light
4
Put the ladder back into its storage housing.
Visible:RED light
5
Release the emergency stop (red button).
Visible:RED light
6
Close the landing door.
Visible:RED light
7
Turn the key on the “RESET” switch outside the landing to reset the
electrical panel functions (buzzer).
Visible: no light
8
The lift is back in service (floor call buttons are not lit).
Visible: no light
