Goblin 420 - Page 15

14 mm
The distance between the servo spline
and the ball must be between 13-15 mm
You can use the SAB servo horn [HA053].
Uniball M2
5H6
(H0064-S)
Socket Head
Cap M2x8mm
(HC008-S) Tail Servo
Bag 6
Socket Head Cap
Screw M2.5x10mm
(HC022-S)
Servo Spacer
(H0572-S)
Servo Spacer
(H0572-S)
Socket Head Cap M3x6mm
(HC044-S)
Chapter 9, Tail Servo Assembly
Page 13
