840mm
228mm
140mm
SPECIFICATIONS
Main rotor diameter : 936mm.
Main blade length : 420mm.
Tail rotor diameter : 192mm.
Tail blade length : 70mm.
Main shaft diameter : 8mm.
Tail shaft diameter : 5mm.
Spindle diameter : 5mm.
Motor size: Maximum 41mm diameter, maximum height 41mm.
Battery compartment: 44x44x130mm.
13 – Tail Assembly
14 – Installation of the Boom, Canopy
15 – Battery
16 – In flight
17 – Maintenance
18 – Exploded Views
19 – Spare Parts
INDEX
1 – Specifications
2 – Important Notes
3 – Components and Box
4 – Carbon frame Assembly
5 – Transmission Assembly
6 – Main Rotor Assembly
7 – Assembling The Modules
8 – Installation of Swashplate Servos
9 – Tail Servo Assembly
10 – Installation of The Motor
11 – Installation of The ESC
12 – Installation of Flybarless Unit and RX
It is extremely important that you take a moment to register your helicopter with us. This is the only way to ensure that you are
properly informed about changes to your kit, such as upgrades, retrofits and other important developments. SAB Heli Division
cannot be held responsible for issues arising with your model and will not provide support unless you register your serial number.
The Serial number is also engraved in the Aluminum Main Plate.
Thank you for your purchase, we hope you enjoy your new Goblin helicopter!
SAB Heli Division
http:
//www.goblin-helicopter.com
VERY IMPORTANT
In the Manual bag you will find a product card your with serial number. Please take a moment to register
your kit online via our web site at:
Please read this user manual carefully, it contains instructions for the correct assembly of the model.
Please refer to the web site www.goblin-helicopter.com for updates and other important information.
Page 1
Chapter 1, Specifications
