Goblin 420 - Page 39

[HC418-S] [HC419-S] [HC435-S] [HC440-S] [HC448-S]
[HC450-S] [HC453-S] [HC454-S]
[HC465-S]
[HC456-S] [HC457-S]
[HC458-S]
[HA021-S] [HA032-S] [HA035-S]
[HC459-S] [HC460-S]
[HA016-S]
- 2 x Flanged Bearing
Ø8xØ12x3.5mm.
- 2 x Bearing
Ø8xØ16x5mm.
- 2 x Thrust Bearing
Ø5xØ10x4mm.
- 5 x Washer
Ø5xØ7x0.1mm.
- 2 x Oring DI=6,75, S=1,78.
- 2 x Oring DI=2.9, S=1,78. - 1 x Belt 304-2GT-09.
- 1 x Belt 1250-HTD-2.
- 4 x Bearing Ø3Ø6x2.5mm.
- 4 x Canopy Grommet. - 1 x Foam Blade Holder.
- 1 x One Way Bearing
Ø8xØ12x12mm.
- 2 x Thrust Bearing
Ø3xØ6x2.5mm.
- 4 x Flanged Bearing
Ø2xØ5x2.5mm.
- 4 x Bearing Ø3Ø7x3mm.
- 1 x Rad Bearing
Ø25Ø32x4mm.
- 1 x Spherical Bearing
Ø12xØ22x7mm.
- 2 x Double-sided Tape
1 mm Battery .
[HC464-S]
- 1 x Tail Push Rod
Ø4xØ2,5x473mm.
- 2 x Plastic Ball Link.
- 2 x Thread Rod M2,5.
[HC462-S]
- 4 x Shim Ø8xØ12x0.1mm.
- 2 x Wrench Tool M8,M6.
[HA036-S]
- 1 x Tail Servo Horn.
- 3 x Cyclic Servo Horn.
- 2 x Battery Straps. - 2 x Main Blade 420mm. - 2 x Tail Blade 70mm.
- 1 x Canopy Edge
Protection (1m).
[HA052-S] [420TB-3DS] [BW0370-S] [HA112-S]
