10
On all legs: Raise the top of the leg until
the leg is the desired height. Re-install the
height screws, washer and nut.
3
Important: Set all the legs to the same height
hole.
On all legs: Re-tighten the set screws with
the 4 mm Allen wrench. The middle leg has
only one set screw.
4
Note: Final height may vary slightly after
adjusting the leveling feet (see page 24).
Set Screws
Setting the Frame Height (Continued)
Full Frame Assembly
