Grace Continuum II - Using the Channel Locks

71
Using the Channel Locks
On both channel locks: If the rubber foot
doesn’t reach the bottom carriage track,
twist it to extend it until it does.
On both channel locks: Flip down the arm
on the machine channel lock to close the
channel lock.
1
2
Instructions
The channel locks assist with stitching in a straight line by inhibiting the movement of the bottom
carriage or machine.
On both channel locks: To prevent the
rubber foot from loosening over time, use
needle nose pliers or a wrench to tighten
the bottom 4 mm hex nut against the
rubber foot. Tighten the other hex nut
against the channel lock barrel.
3
Channel
Lock Arm
Rubber
Foot
4 mm Hex
Nut
Channel
Lock Barrel
Using Your Frame
