40
Crib Frame Assembly
Step 1 - Setting the Frame Height
Parts & Tools Needed:
Right Leg
Left Leg
Open-ended Wrench
10 mm & 13 mm
Allen Wrench 5 mm
Instructions
The frame height is most easily adjusted prior to frame assembly. Please take the following steps:
On both legs: Raise the top of the leg until
the leg is the desired height. Re-install the
height screws, washer and nut.
On both legs: Remove the height
screws, washer, and nut with the 10 mm
box-end wrench and 5 mm Allen wrench.
1 2
Important: Set all the legs to the same hole.
Note: Final height may vary slightly after
adjusting the leveling feet (see page 51).
(Box 1)
(Box 1)
(Box 1: Inner Box) (Box 1: Inner Box)
Nut (x2)
Height
Screw (x2)
Washer (x2)
