Graco EcoQuip 2 User Manual

Operation
Winterizing Winterizing
Winterizing
the the
the
Equipment Equipment
Equipment
NOTICE NOTICE
NOTICE
Vaporabrasiveblastersmustbewinterized
wheneverthereisapossibilityoffreezing
temperaturesduringstoragetoavoiddamageto
theequipment.
1.Drainthepot(seeDrainingthePot,page22).
2.Drainthewatertankbydisconnectingthepump
inlethoseandopeningtheinletballvalve.
NOTE: NOTE:
NOTE:
Alldisposalsmustcomplywithnational,
state,andlocalregulations.
3.Drainthepumpinlethose,theninserttheend
intoawindshieldwashcontainer.Choosea
windshieldwashwitharatingthatwillprotectthe
equipmentforthelowesttemperaturesinyour
area.
4.EQm EQm
EQm
and and
and
EQs2 EQs2
EQs2
Elite Elite
Elite
only: only:
only:
Disconnectthewater
inletregulatorfromthepumpandinstallthe
winterizingtube.Insertthewinterizingtubeinto
awindshieldwasher󰘱uidcontainer.Continue
tostep5.
5.TurntheselectorvalvetoWASHandopenthe
rinseballvalve.Whileholdingtherinsehose
overthepot,runthepumpuntilwindshieldwash
comesoutoftherinsehose.
6.Movetheselectorvalveintotheothertwo
positions(BLASTandOFF).Con󰘰rmthatthe
internalwatertubing󰘰llswithwindshieldwash
beforeturningtheselectorvalvetothenext
position.
NOTE: NOTE:
NOTE:
Allwatertubingshouldbe󰘰lledwith
windshieldwashforfullprotection.
7.Engagetheemergencystop(Q).
8.Reconnectthepumpinlethosetotheinletball
valve.
9.Makesurethattherinseballvalve(X)andthe
inletballvalve(N)areleftopen.
NOTICE NOTICE
NOTICE
Wheniceformsbehindtheseals,thesealscan
becomedamaged.Duringstorage,positionall
ballvalvesintheopenposition.
3A3489E 23
