Graco EcoQuip 2 User Manual

TubingSchematic
Tubing Tubing
Tubing
Schematic Schematic
Schematic
Cut Cut
Cut
Length Length
Length
inches inches
inches
(mm) (mm)
(mm)
Ref. Ref.
Ref.
Part Part
Part
Color, Color,
Color,
Tube Tube
Tube
Size Size
Size
EQ2M EQ2M
EQ2M
EQ2S EQ2S
EQ2S
EQ2S EQ2S
EQ2S
Elite Elite
Elite
1
EQ1273Natural,3/8inOD12.25(311)12.25(311)12.25(311)
2
EQ1273Natural,3/8inOD15.5(394)17(432)17(432)
3
EQ1273Natural,3/8inOD7.25(184)7.25(184)7.25(184)
4
EQ1273Natural,3/8inOD5.25(133)5.25(133)5.25(133)
5
EQ1273Natural,3/8inOD2.25(57)2.25(57)2.25(57)
6
EQ1273Natural,3/8inOD6(152)6(152)6(152)
7
EQ1273Natural,3/8inOD
--
5.25(133)
8
EQ1273Natural,3/8inOD
--
4.5(114)
9
EQ1881Natural,1/4inOD24(610)27(686)27(686)
10
EQ1297Red,3/8inOD10.5(267)13.5(343)13.5(343)
11
EQ1297Red,3/8inOD6.25(159)7.25(184)7.25(184)
12
EQ1297Red,3/8inOD18.75(476)27(686)27(686)
13
EQ1882Red,1/4inOD9.5(241)12.5(318)12.5(318)
14
EQ1883Blue,1/4inOD7.5(191)7.5(191)7.5(191)
15
EQ1883Blue,1/4inOD21.5(546)21.5(546)21.5(546)
16
EQ1885Yellow,1/4inOD22.5(572)22.5(572)22.5(572)
17
EQ1885Yellow,1/4inOD9.25(235)9.25(235)9.25(235)
18
EQ1884Green,1/4inOD12.5(318)8.25(210)8.25(210)
19
EQ1884Green,1/4inOD23(584)23(584)23(584)
20
EQ1884Green,1/4inOD23(584)23(584)23(584)
21
EQ1884Green,1/4inOD18(457)18(457)18(457)
22
EQ1296Orange,1/4inOD13(330)13(330)13(330)
3A3489E 63
