Graco EcoQuip 2 - Page 42

Parts
EQs2 EQs2
EQs2
(continued) (continued)
(continued)
1.Applythreadsealanttoallnon-swivelpipe
threads.
2
Applyanti-seizetothreads.
3
Torqueto60+/-5ft-lb(81.3+/-6.7N•m)
withpotpressurized.
4
Torqueto15+/-2ft-lb(20.3+/-2.7N•m).
5
Applyanti-seizetoenclosuremounting
studs.
6
Torqueto25–30ft-lb(34–40.6N•m).
7
Thehandwaygasketmustbeassembled
centeredand󰘱atonthehandwaycover.
8
Applyanaerobicsealanttothreads.
42
3A3489E
