Parts
Enclosure Enclosure
Enclosure
Parts Parts
Parts
(EQm (EQm
(EQm
only) only)
only)
1
Assemblevalve(17)withplungerfacingthe
bentmanifold(16).
2
Applyanti-seizetothreadsonclamp(62).
Alignthenutspointingtowardsthefrontof
theenclosure.Torquenutsto85+/-5in-lb
(9.6+/-0.5N•m).
3
Applyanti-seizetothreadsonclamp(60).
Alignthenutspointingtowardsthefrontof
theenclosure.Torquenutsto15+/-2ft-lb
(20.3+/-2.7N•m)
*IncludedinKit17C127.
†IncludedinKit17L412.
56 3A3489E
