Parts
40 3A8099A
PerformAA 15 Air Assist Gun Models
Models 26B500, 26B501, 26B502, 26B503,
26B504, and 26B505
Ref.
No.
Part No. Description Qty.
1---BODY, gun 1
2 188493 PACKING, U-CUP, gun 1
3 249423 STOP, TRIGGER (includes
item 4)
1
4 115132 PIN, DOWEL 2
6 CARTRIDGE, FLUID, see
Fluid Cartridge Assembly,
page 48
26B700 CARTRIDGE, FLUID
(Models 26B500 and
26B501)
1
26B701 CARTRIDGE, FLUID,1500,
SST Plastic (Model
26B504)
1
26B702 CARTRIDGE, FLUID, WL,
LV (Models 26B502, and
26B503, 26B505)
1
7 --- SPRAY TIP, Customer's
Choice of AXM or AXF, See
Spray Tip Charts, page 50
1
8 --- AIR CAP, ASSY., see Air
Cap Selection Guide,
page 54
1
8a 2GF042 AIR CAP, general finishing
(Models 26B500, 26B501,
and 26B504)
1
2WL042 AIR CAP, wood lacquer
(Models 26B502 and
26B503)
1
2LV042 AIR CAP, low viscosity
(Model 26B505)
1
8b 26B800 RING, RETAINING
(includes 8c and 8d)
1
8c 15G320 WASHER, PTFE 1
8d 109213 PACKING, O-ring, PTFE 1
9 26B721 TRIGGER, GUN (includes
10 and 11)
1
10 15F739 PIN, PIVOT 1
11 15F740 PIN, PIVOT, NUT 1
13 26B711 KIT, FLUID TUBE, filter
(includes 14, 15, and 17),
See Fluid Tube Assembly
Parts, page 49.
1
14 205264 FILTER, TIP 1
15 24D437 FITTING, HOSE, filter 1
16 26B867 FITTING, AIR 1
17 119996 SCREW, CAP, SCKT, LH,
1/4-20X3/8
1
18 --- PLUG, FAN AIR (purchase
kit 26B715: includes 18, 19,
and 20)
1
19 112319 PACKING, O-RING 1
20 --- TUBE, FAN AIR (purchase
kit 26B715: includes 18, 19,
and 20)
1
21 26B713 CARTRIDGE, AIR VALVE
(includes item 2 and 28)
See Air Cartridge
Assembly, page 47
1
22 189018 SWIVEL (Models 26B501,
26B503, 26B505)
1
25 117642 TOOL, NUT DRIVER, 5/16” 1
26 222385 LABEL, SAFETY,
WARNING, MED. ALERT,
not shown
1
27 172479 TAG, INSTRUCTION, not
shown
1
28 192282 TOOL, INSTALLATION,
SEAL
1
29 15F446 TOOL, GUN 1
Replacement safety labels, tags, and cards are
available at no cost.
