Spray Tip Charts
3A8099A 53
PerformAA RAC SwitchTips
PerformAA RAC models are compatible with the
following RAC spray tips:
LTX RAC Spray Tips (LTXxxx): Recommended for
high pressure RAC spray gun models.
FFLP Fine Finish Low Pressure (FFLPxxx):
Recommended for low pressure, fine finish applications
for less over-spray and a consistent finish.
LTX and FFLP SwitchTips are the typical tips chosen,
but the PerformAA RAC is also compatible with Low
Pressure (LPxxxx) and Wide (WRxxxx) tips.
Order desired tip, where xxx = 3-digit spray tip Part No.
from the matrix table. Example: Order LTX209 for the
LTX RAC Spray tip with a 0.009 in. (0.229 mm) orifice
and a maximum spray pattern of
2 to 4 in. (100 mm).
Convert PerformAA 50 models to a RAC Model with
RAC Conversion Kit 24C791. Standard and acetal
(solvent resistant) gasket kits are available. See
Reverse-a-Clean Kits, page 56.
.
Orifice Size in.
(mm)
* Fluid Output
2000 psi
(14.0 MPa, 140
bar)
fl oz/min (lpm)
Maximum Pattern Width at 12 in. (305 mm)
in. (mm)
2 to 4 (100) 4 to 6 (150)
6 to 8
(200)
8 to 10
(250)
10 to 12
(300)
12 to 14
(350)
14 to 16
(400)
16 to 18
(450)
Spray Tip Part No.
LTX RAC Spray Tips
0.009 (0.229) 11.2 (0.33) 109 209 309 409 509 --- --- ---
0.011 (0.279) 16.6 (0.49) 111 211 311 411 511 611 --- ---
0.013 (0.330) 23.3 (0.69) --- 213 313 413 513 613 --- ---
0.015 (0.381) 30.8 (0.91) 115 215 315 415 515 615 --- ---
0.017 (0.432) 39.5 (1.17) --- 217 317 417 517 617 --- 817
0.019 (0.483) 49.7 (1.47) --- 219 319 419 519 619 --- 819
0.021 (0.533) 60.5 (1.79) --- 221 321 421 521 621 721 821
0.023 (0.584) 72.7 (2.15) --- --- 323 423 523 623 723 ---
0.025 (0.635) 85.9 (2.54) --- 225 325 425 525 625 --- ---
0.027 (0.686) 100.0 (2.96) --- 227 327 427 527 627 --- 827
0.029 (0.737) 115.6 (3.42) --- --- 329 429 529 629 729
0.031 (0.787) 131.8 (3.90) --- 231 331 431 531 631 --- 831
0.033 (0.838) 149.4 (4.42) --- --- --- 433 533 633 --- 833
0.035 (0.889) 168.4 (4.98) --- 235 335 435 535 635 735 835
FFLP Fine Finish Low Pressure RAC Spray Tips
0.008 (0.203) 8.8 (0.26) 108 208 308 --- --- --- --- ---
0.010 (0.254) 13.9 (0.41) 110 210 310 410 510 --- --- ---
0.012 (0.305) 19.9 (0.59) 112 212 312 412 512 612 --- ---
0.014 (0.356) 27.0 (0.80) --- 214 314 414 514 614 --- ---
0.016 (0.406) --- --- --- --- 516 616 --- ---
0.018 (0.457) --- --- --- --- 518 618 --- ---
0.020 (0.51) --- --- --- --- 520 620 --- ---
*Tips are tested in water.
Measured with NO airflow. Air assist will tend to reduce pattern lengths by 1 in. to 2 in.
Fluid output (Q) at other pressures (P) can be calculated by this formula: Q = (0.041) (QT) where QT = fluid
output (fl oz/min) from the above table for the selected orifice size.
