Maintenance
3A8099A 19
Maintenance
Daily Gun Care
1. Follow the Pressure Relief Procedure, page 15.
2. Remove the air cap assembly (8) and spray tip (7).
3. Flush the gun with a compatible solvent. Follow the
Flushing Procedure, page 21.
4. Soak the spray tip (7) in a compatible solvent.
5. Clean the air cap (8a), spray tip (7), and the outside
of the fluid cartridge (6) with a soft-bristle brush. See
Cleaning Procedure, page 22.
To reduce the risk of an injury, follow the Pressure
Relief Procedure, page 15, whenever you are
instructed to relieve the pressure.
FIG. 25: Relieve the pressure
FIG. 26: Remove the air cap assembly and spray tip
NOTICE
Methylene chloride with formic or propionic acid will
damage aluminum and nylon components. Do not use
to flush or clean the gun.
8
7
FIG. 27: Flush the gun
FIG. 28: Soak the spray tip
FIG. 29: Clean parts with a soft-bristle brush
7
8
7
6
