Parts
42 3A8099A
PerformAA 50 Air Assist Gun Models
Models 26B509, 26B510, 26B511, 26B512
26B513, 26B514, 26B515, and 26B516
Ref.
No.
Part No. Description Qty.
1---BODY, gun 1
2 188493 PACKING, U-CUP, GUN 1
3 249423 STOP, TRIGGER (kit
includes item 4)
1
4 115132 PIN, DOWEL 1
6 26B700 CARTRIDGE, FLUID, see
Fluid Cartridge Assembly,
page 48
1
7 --- SPRAY TIP, Customer's
Choice of AXM or AXF, see
Spray Tip Charts, page 50
1
8 AIR CAP, ASSY., see Air
Cap Selection Guide,
page 54.
1
8a 2GF042 AIR CAP, general finishing
(26B510, 26B511, 26B509)
1
2WL042 AIR CAP, wood lacquer
(26B512)
1
2HV042 AIR CAP, high viscosity
(26B513)
1
2WB042 AIR CAP, waterborne
(26B514)
1
2QD042 AIR CAP, quick drying
(26B515)
1
2LV042 AIR CAP, low viscosity
(26B516)
1
8b 26B801 RETAINING RING (kit
includes 8c and 8d)
1
8c 15G320 WASHER, PTFE 1
8d 109213 PACKING, O-ring, PTFE 2
9 26B721 TRIGGER,GUN (kit
includes 10 and 11)
1
10 15F739 PIN, PIVOT 1
11 15F740 PIN, PIVOT, NUT 1
13 26B711 KIT, FLUID TUBE, filter, all
models except 26B509, (kit
includes 14, 15, and 17)
See Fluid Tube Assembly
Parts, page 49.
1
13 26B712 KIT, FLUID TUBE, high flow
model 26B509 (kit includes
17), see Fluid Tube
Assembly Parts, page 49.
1
14 205264 FILTER, TIP (not included
in 26B509), see Inline
Fluid Filter Kits, page 55
1
15 24D437 FITTING, HOSE, FILTER
(not included in 26B509)
1
16 26B867 FITTING, AIR 1
17 119996 SCREW, CAP, SCKT, LH,
1/4-20X3/8
1
18 --- PLUG, FAN AIR, (purchase
kit 26B715: includes 18, 19,
and 20)
1
19 112319 PACKING, O-RING 1
20 --- TUBE, FAN AIR (purchase
kit 26B715: includes 18,
19,20)
1
21 26B713 CARTRIDGE, AIR VALVE
(kit includes item 2 and 28),
see Air Cartridge
Assembly, page 47
1
22 189018 SWIVEL (Models 26B511,
26B512, 26B513, 26B514,
26B515, and 26B516)
1
25 117642 TOOL, NUT DRIVER, 5/16” 1
26 222385 LABEL, SAFETY,
WARNING, MED. ALERT,
not shown
1
27 172479 TAG, INSTRUCTION, not
shown
1
28 192282 TOOL, INSTALLATION,
SEAL
1
29 15F446 TOOL, GUN 1
Replacement safety labels, tags, and cards are
available at no cost.
