Parts
44 3A8099A
PerformAA RAC Air Assist Gun Models
Models 26B517and 26B518
Ref
No.
Part No. Description Qty.
1---BODY, gun 1
2 188493 PACKING, U-CUP, GUN 1
3 249423 STOP, TRIGGER (kit
includes item 4)
1
4 115132 PIN, DOWEL 2
6 26B703 CARTRIDGE, FLUID, see
Fluid Cartridge Repair
Kits, page 55
1
7 15F442 HOUSING, RAC 1
8 26B869 AIR CAP, RAC,
PERFORMAA (kit includes
8a)
1
8a 109213 PACKING, O-ring, PTFE
9 15E557 GASKET, TIP 1
10 --- SPRAY TIP, Customer's
Choice of LTX or FFLP,
see PerformAA RAC
SwitchTips, page 53.
1
11 15A981 SEAT, CYLINDER 1
12 26B721 TRIGGER, GUN (kit
includes 13 and 14)
1
13 15F739 PIN, PIVOT 1
14 15F740 PIN, PIVOT, NUT 1
16 26B712 KIT, FLUID TUBE, high
flow (includes 18). See
Fluid Tube Assembly
Parts, page 49.
1
17 26B867 FITTING, AIR 1
18 119996 SCREW, CAP, SCKT, LH,
1/4-20X3/8
1
19 --- PLUG, FAN AIR, (purchase
kit 26B715: includes 19 and
20)
1
20 112319 PACKING, O-RING 1
21 26B717 CARTRIDGE, AIR VALVE,
FIXED (kit includes item 2
and 28), Air Cartridge
Assembly, page 47
1
22 189018 SWIVEL (Model 26B518) 1
25 117642 TOOL, NUT DRIVER, 5/16” 1
26 222385 LABEL, SAFETY,
WARNING, MED. ALERT,
not shown
1
27 172479 TAG, INSTRUCTION, not
shown
1
28 192282 TOOL, INSTALLATION,
SEAL
1
29 15F446 TOOL, GUN 1
Replacement safety labels, tags, and cards are
available at no cost.
