Parts
46 3A8099A
PerformAA Airless Gun Models
Models 26B519 and 26B520
Ref.
No.
Part
No.
Description Qty.
1 --- BODY, gun 1
2 188493 PACKING, U-CUP, gun 1
3 249423 STOP, TRIGGER (kit includes
item 4)
1
4 115132 PIN, DOWEL 2
6 26B700 CARTRIDGE, FLUID, see Fluid
Cartridge Assembly, page 48
1
7 --- Spray Tip, Customer's Choice of
AXM or AXF, see Spray Tip
Charts, page 50
1
8 --- AIR CAP, ASSY., airless 1
8a 2AL042 AIR CAP, airless 1
8b 26B800 RETAINING RING, model 26B519
(kit includes 8c and 8d)
1
8b 26B867 RETAINING RING, model 26B520
(kit includes 8c and 8d)
1
8c 15G320 WASHER, PTFE 1
8d 109213 PACKING, O-RING, PTFE 1
9 26B721 TRIGGER, GUN, (kit includes
items 10 and 11)
1
10 15F739 PIN, PIVOT 1
11 15F740 PIN, PIVOT, NUT 1
13 26B711 KIT, FLUID TUBE, filter (kit
includes 14, 15, and 17) See Fluid
Tube Assembly Parts, page 49.
1
14 205264 FILTER, TIP, see Inline Fluid
Filter Kits, page 55 for options
1
15 24D437 FITTING, HOSE, filter 1
16 26B868 PLUG, AIR, AIRLESS 1
17 119996 SCREW, CAP, SCKT, LH,
1/4-20X3/8
1
18 --- PLUG, FAN AIR (Purchase kit
26B715: includes 18 and 19)
1
19 112319 PACKING, O-RING 1
21 26B717 CARTRIDGE, AIR VALVE, FIXED
(kit includes item 2 and 28) See
Air Cartridge Assembly, page 47
1
23 117642 TOOL, NUT DRIVER, 5/16" 1
24 222385 LABEL, SAFETY, WARNING,
MED. ALERT, not shown
1
25 172479 TAG, INSTRUCTION 1
26 192282 TOOL, INSTALLATION, SEAL 1
27 15F446 TOOL, GUN 1
Replacement safety labels, tags, and cards are
available at no cost.
