Graco Reactor 2 Series User Manual

Component Identification
Generator
Figure 5
AF Air Filter
BE
Battery (not supplied)
DF Diesel Fuel Filter
EA
12V Charge Alternator
EB
Engine Coolant Expansion Bottle
EE Engine
ED
Engine Oil Dipstick
ER Radiator
EX Exhaust
FD
Fuel Shutoff Solenoid
FH Filter Housing
FJ Fuel Injector
FP Fuel Pump
FS Diesel Fuel Fill Cap
FT Diesel Fuel Tank
GD Gen
erator Power Distribution Box
GL Glo
wPlugs
HB
Hea
t Exchanger Coolant Expansion Bottle
HE Heat Exchanger
HF
He
at Exchanger Coolant Fill Bottle
OD Oi
lDrain
OF Oi
lFilter
O
L
O
il Fill
O
S
O
il Pressure Switch
R
C
E
ngine Coolant Radiator Cap
RF Radiator Fan
S
T
S
tarter
TR Coolant Temperature Sensor
WS Over-Temperature Switch
