Graco Reactor 2 Series User Manual

Models
Models
Reactor 2 E-30i
All base systems include fluid inlet pressure and temperature sensors and Graco InSite
™
. For part numbers,
see Accessories, page 12.
No Air Compressor/Dryer With Air Compressor/Dryer
Model
E-30i E-30i with heat E-30i E-30i with heat
Base Machine 272079 272080 272089 272090
Maximum Fluid
Working Pressure
psi (MPa, bar)
2000 (13.8, 138) 2000 (13.8, 138) 2000 (13.8, 138) 2000 (13.8, 138)
Approximate Output
per Cycle (A+B) gal.
(liter)
0.0272 (0.1034) 0.0272 (0.1034) 0.0272 (0.1034) 0.0272 (0.1034)
Max Flow Rate lb/min
(kg/min)
30 (13.5) 30 (13.5) 30 (13.5) 30 (13.5)
Total System Load †
(Watts)
7,400 11,600 13,500 17,700
Voltage (phase) 240 VAC (1) 240 VAC (1) 240 VAC (1) 240 VAC (1)
Available Auxiliary
Current at Volts, 60
Hz*
52 Amps (240) 35 Amps (240) 22 Amps (240)
9 Amps (120)
5 Amps (240)
9 Amps (120)
Fusion AP Package 
(Gun Part No.)
AP2079
(246102)
AP2080
(246102)
AP2089
(246102)
AP2090
(246102)
Fusion CS Package 
(Gun Part No.)
CS2079
(CS02RD)
CS2080
(CS02RD)
CS2089
(CS02RD)
CS2090
(CS02RD)
Probler P2 Package 
(Gun Part No.)
P22079
(GCP2R2)
P22080
(GCP2R2)
P22089
(GCP2R2)
P22090
(GCP2R2)
Heated Hose
50 ft (15 m)
24Y240 24Y240 24Y240 24Y240
Heated Whip Hose
10 ft (3 m)
246055 246055 246055 246055

Total system watts used by system, based on
maximum heated hose length of 310 ft (94.5 m)
for each unit.
* Full load amps available for auxiliary equipment
when all bare-system components are operating
at maximum capabilities. Available auxiliary
current is based on 310 ft (94.5 m) of heated hose.
An additional 3.0 amps (240 VAC) of auxiliary
current is available for each 50 ft (15.2 m) section
of heated hose that is not used.
Auxi
liary current at 120 VAC is available on CB08,
lin
e 1 (circuit breaker pin 2), line 2 current at 120
VAC
is used by the air dryer (circuit breaker pin 4).

Available auxiliary current will be less when the
engine is de-rated for site altitude. Reduce the
Available Auxiliary Current in the chart by 2.5
Amps (240 VAC) per 1000 ft (300 m) elevation
increments. If the available auxiliary current is
less than zero, the system configuration may not
support the full load at that altitude.

Includes Complete Air Compressor/Dryer Kit
24U176.
Refer to Circuit Breaker Configuration Options,
page 33.

See Approvals, page 12.

Packages include gun, heated hose, and whip
hose.
10 332636C
