Graco Reactor 2 Series User Manual

Technical Specifications
Reactor 2 Elite Integrated Proportioning Systems
U.S.
Metric
Maximum Fluid Working Pressure
E-30i 2000 psi 14 MPa, 140 bar
E-XP2i 3500 psi 24.1 MPa, 24
1bar
Maximum Fluid Temperature
E-30i
150°F 65°C
E-30i with booster heater
180°F 82°C
E-XP2i 180°F 82°C
Maximum
Output
E-30i 30 lb/min 13.5 kg/min
E-XP2i 2 gpm 7.6 lpm
Maxim
um Heated Hose Length
Length
310 ft
94 m
Output per Cycle
AandB
E-30i 0.0272 gal. 0.1034 liter
E-XP2i 0.0203 gal. 0.0771 liter
Operating Ambient Temperature Range
Te
mperature
20° to 120°F -7° to 49°C
Auxiliary Power Available
Voltage 120 Vac or 240 Vac, 60 Hz
Engine
Model Perkins 404–22G, 2.2 L, 29 HP
Alternator
Model Mecc Alte 22 kW, 240 V, 1 PH, 60 Hz, pancake style
Battery Requirements
Voltage 12 Vdc
Minimum Cold Cranking Amps 800 CCA
Connection Type Post Style
