Appendix A: Engine Control Module
Appendix A: Engine
Control Module
Run Screens
There are seven run screens on the engine control module:
Line-to-neutral voltage
Line-to-line voltage
Frequency
Engine Speed
Engine lifetime counter
Battery voltage
Press
to scroll through the run screens. Press to enter the Information screens.
Run Screen Layout
Inst
Icon
Alarm
Icon
Instrumentation Units
Mode
Icon
Information Screens
From the Run Screen, press to enter the information screens. Press to scroll through the last five
generator events.
Press
to return to the Run Screens.
Information Screen Layout
Alarm
Icon
Event
#
Time of Event (Engine
Run Hours)
Units
Mode
Icon
