Display during program execution (fig. 32)
Thetoplineshowsthephaseoftheprogramexecutioncurrentlyrunningdependingupontheprogram
selected:
Free
z
ing,

Storage,

Thawing,

Proving,

Holding

Thefieldintheupperright
rectangleshowsthe
currentlyrunningprogram
phaseandtheassociated
remaining(residual)time.
Aredtriangleisshownas
analarmsymbolinthe
eventofanalarm.
Thecurrentvalueforthe
temperatureortherelative
humidityisshowninthe
lowerrightcorner
dependinguponthe
programphase.
Thegreenbaratthe
bottomofthedisplay
showsthetotalprogram
executioninproportion
totheduration.
Inthewindowinthemiddle,the
symbolforthecurrently
runningprogramisshownatthe
left,inthecentretheendingtime
fortheprogramandattherighta
buttontointerrupttheprogram.
