P a g e | 72

GRP261X User Guide

Version 1.0.5.33

Table 15: VPK Modes Icon Indications

VPK Mode

Description

Default

Reverse

LINE

Unregistered

Registered

Call Forward

Dial_1_open_voicemail

Dial_2_open_voicemail

Account_1_open_voicemail

Account_2_open_voicemail

SCA

Connect

Hold

Idle

Ringing

Seized

Error

Invalid

Unknown

BLF

Away

Available

Unavailable

Busy

Chat

Connect

DND

Ringing
