CALL HISTORY

Local Call History

There are five different categories in the local call history. Users could use the navigation keys to browse

call logs:

• All :

• Missed :

• Dialed :

• Answered :

• Transferred :

Figure 72: Call History Screen Page

• Dial: Tap on one of the call history entry to call this number directly. The phone will use the same

account as the call log when dialing out.

• Delete: Select an entry then press “Delete” soft key

• DeleteAll: Clear the call history
