Grandstream Networks, Inc. GXV3615 User Manual Page 11 of 37
Firmware Version 1.0.4.38 Last Updated: 03/2013
GXV3615 Specifications
Table 1: GXV3615 Technical Specifications
Models
GXV3615 (PoE) or GXV3615W (Wi-Fi)
Video Compression
H.264, MJPEG , JPEG
Image Sensor
1/4”, CMOS, 680H x 512V pixel resolution, excellent
low noise levels and low-light sensitivity
Lens Type
1/4”, M12, f=4.5mm, F1.5, View Angle = 64
Minimum Illumination
0.05Lux
Responsivity
11.5V/lux-sec (550nm)
Max Video Resolution
704x480, 352x240, 176x112;
704x576, 352x288, 176x144;
640x480, 480x272, 320x240, 256x192, 160x112.
Pixel Dynamic Range
82dB
Max Frame Rate in Max Resolution
30fps
Video Bit Rate
16 Kbps – 2 Mbps
Audio Input
Built-in Microphone
Audio Output
Built-in Speaker
Audio Compression
G.711u/a, G.726
Video Management System
ONVIF compliant, HTTP API for advanced integration
Pre/Post-Alarm Buffer
24MB
Snapshots
Triggered upon events, send via email/FTP
Multi-streaming-rate for Preview &
Recording
Yes, Primary and Secondary Stream
Security
Login password, HTTPS for firmware upgrade
Network Port
10M/100M auto-sensing, RJ45
Network Protocol
TCP/UDP/IP, RTP/RTCP, RTSP, DHCP, DDNS,
HTTP/HTTPS, SMTP, FTP, NTP, PPPoE
Power over Ethernet (PoE)
IEEE 802.3af class 0 (GXV3615 only)
Wi-Fi (802.11b/g/n)
Internal antenna (GXV3615W only)
SIP/VoIP Support
Yes, Voice & Video-over-IP
Dimensions (W x H x L)
90mm x 90mm x 45mm
Weight
GXV3615: 128 gram.
GXV3615W: 133 gram (base only)
Stand: 121 gram
Package Weight: 568 gram
Temperature / Humidity
0°C – 45°C (32°F–113°F)
Humidity 10–90% RH (non–condensing)
Power Adapter
Output: 12VDC/0.5A; Input:100–240VAC, 50–60Hz
Package Content
GXV3615 (or GXV3615W) Base Unit;
Desk Stand (also as wall-mounting kit);
Universal Power Supply;
Network Cable;
Quick Installation Guide
Regulatory Compliance
FCC, CE, C-tick
