HT801/HT802 Administration Guide
Version 1.0.13.7
Product Model
Displays product model info. Default is HT801/HT802.
Hardware Version
Displays the hardware revision information and the part number.
Software version
• Program: Specifies Program version. This is the main firmware release
number, which is always used for identifying the software system of the
HT801/HT802.
• Bootloader: Specifies Boot version.
• Core: Specifies Core version.
• Base: Specifies Base version.
• CPE: Specifies CPE version. CPE version is displayed only when
HT801/HT802 is connected to an ACS using TR-069 protocol.
Software Status
Indicates actual software status.
System Up Time
Indicates actual system time and uptime since last reboot.
CPU Load
Indicates CPU load (%)
Network Cable Status
Indicates physical network cable status:
Status (Up/Down), Speed (Mbps), Operational Mode (Full/Half Duplex)
PPPoE Link Up
Indicates PPPoE connection status.
NAT
Indicates type of NAT when it’s configured.
Port Status
Displays relevant information regarding the FXS ports, their registration,
current status and their appropriate User ID.
Port Options
Displays DND and call forward information on FXS ports.
CDR File
Download, Preview. Or, Delete call history records from the web GUI. Only
the last 1000 records will be available.
SIP File
Download, Preview or, Delete locally stored SIP trace.
Note: “Send SIP Log” must be enabled to be able to capture the trace.
Provision
Displays provisioning status.
Core Dump
Provides generated core dump file if unit malfunctions.
Clean will be displayed if no issues.
GR909
Click on “Test Page” to be redirected to lines tests page (Hazardous
Potential, Foreign Electromotive Forces, Resistive Faults, Receiver Off hook
and Ringer Equivalent Number)
