HT801/HT802 Administration Guide
Version 1.0.13.7
There are 3 types of factory reset:
• ISP Data Reset: All VoIP related configuration (mainly everything
located on FXS page).
• VOIP Data Reset: All ISP (Internet Service Provider) configuration
which may affect the IP address.
• Full Reset: Both VoIP and ISP related configuration at the same time.
Note: After you choose the reset type, you must click the reset button to
take effect.
Advanced Settings Page Definitions
Table 8: Advanced Settings
Defines the administrator level password to access the Advanced Web
Configuration page. This field is case sensitive. Only the administrator can
configure the “Advanced Settings” page. Password field is purposely left
blank for security reasons after clicking update and saved. Max. length is 25
characters.
Confirms the new admin password.
Sets values for 802.1Q/VLAN Tag. Default is 0. Valid range is 0-4094.
SIP 802.1p. Default is 0. Valid range is 0-7.
RTP 802.1p. Default is 0. Valid range is 0-7.
Black List for WAN Side Port
It could be either port range or single port separated by a “,”
Example: “5000-6000, 7000 “.
Configures IP address or domain name of STUN server. Only non-
symmetric NAT routers work with STUN.
Sends periodically a blank UDP packet to SIP server to keep the "ping hole"
on the NAT router open. Default is 20 seconds.
Use STUN to detect network
connectivity
Uses STUN keep-alive to detect WAN side network problems. If keep-alive
request does not yield any response for configured number of times
To Next Page
