WP820 Administration Guide
Version 1.0.1.15
Selects the existing core dump file in the drop-down box. Users could delete the
file by pressing on “Delete” button.
Press “List” button to view all existing core dump files. The files are listed in
chronological order, users could click the file name to download the file to the
local computer.
Click to start capturing audio data, click the "Stop" button to end. To capture the
audio data of the device can help to locate audio issues. The default is not
enabled. You can record up to 1-minute audio data.
Choose the existing audio file. Click the "Delete" button on the right to delete this
file.
Click on the "List" button to view. The captured audio data will be sorted by time.
Click to download the data to the computer for analysis. Users can also delete
files under this folder.
Click the screenshot to capture and save the current phone screen image.
Selects the existing screenshot file and click the "Delete" button on the right to
delete the file.
Click the "List" button to view the existing screenshot file. Click the file name to
open or save the screenshot to the computer.
Configures the IP address or URL for the Target Host of the Traceroute.
Press Start to send traceroute request to configured target host.
Press Stop to end traceroute running process.
Maintenance/Event Notification
Set the URL for events on phone web GUI, and when the corresponding event occurs on the phone, the
phone will send the configured URL (including variables) to destination. The dynamic variables in the URL
will be replaced by the actual values of the phone before sending to destination, in order to achieve the
purpose of events notification. Here are the standards :
1. The IP address of the destination server needs to be added at the beginning. The server address
and dynamic variables needs to be separated with a "/".
