WP810 keypad keys Description
WP822
Figure 7: WP822 Description
12 3.5 mm headset jack Phone connector for the headphones/headsets.
13 Color LCD Screen 1.8-inch (128×160) color LCD
14 Softkeys
Correspond to functions displayed on the LCD. These functions
change depending on the current context.
15 Menu/OK key Displays the main menu
16 On-hook or Power key
Selects the option chosen by the cursor or enters the main menu
from the home screen.
17 # / Lock key
Does one of the following:
● When pressing #: Redials the last dialed number, for this to
work the Key As Send option under Account settings => Call
settings should be set to #
● Lock key: Long press to lock keypad against unintentional
entries, for this to work enable lock screen from LCD settings
under Basic settings => Display
18 Contacts Access to contacts list
19 Microphone Picks up audio earpiece and hands-free calls
