<No>: Cutting is canceled.
<Area>: The Craft ROBO cuts the media after conrming the cutting area.
<Conrmingthecuttingarea>
If you select <Area>, the Craft ROBO moves the tool to the last coordinate of the cutting data and
checks if the cutting area is within the media size. If the cutting data includes registration marks,
the Craft ROBO searches the marks from the origin point automatically, detects the marks, moves
the tool to the last coordinate of the cutting data, and conrms the cutting area.
<OFFSCALE>: The cutting area exceeds the media size. Press [ENTER] to display <Cut?>. To
start cutting, press  or  to select <Yes>, and press [ENTER]. To cancel cutting, press  or 
to select <No>, and press [ENTER].
<PRESS ENTER>: The cutting area is within the media size. Press [ENTER] to display <Cut?>. To
start cutting, press  or  to select <Yes>, and press [ENTER]. To cancel cutting, press  or 
to select <No>, and press [ENTER].
(7) When cutting is complete, make sure that <Unload Media> is displayed, and press [ENTER].

Unload
Media
Load w/
Carrier
The media is output toward the front of the main unit.
Cutting with new tool conditions
(1) Press the standby switch and conrm that the LED lamp is lit (green).
(2) Insert the SD card into the SD card slot.
(3) Load the media, and press [ENTER]. (See Section 2.3, "Loading Media using the Carrier
Sheet," and Section 2.4, "Loading Media without Using the Carrier Sheet (CC330-20 Only).")

Load w/
Carrier
Select
File
(4) Press  or  to select <Setting>, and press [ENTER].

Setting Select
Media
(5) Press  or  to select <Select Media>, and press [ENTER].

Select
Media
Thick
(6) Press  or  to select the media type, and press [ENTER].

Thick Force:33
S+E:TEST
You can select the media type from <Thick>, <Thin>, <Film>, or <Pen>.
The preset force for the selected media type is displayed.
(7) As necessary, press
 or  to adjust the force, perform a test cut, and then press [ENTER].

Force: 10
S+E:TEST
Start
Point
