Planning and Installation Manual 23
When licensed to do so, Broadlinx will also support SNMP/NetCentral
monitoring.
The monitoring network consists of a Windows PC, network interface
connection (NIC) circuitry on the NR-33000 board, and microproces-
sors on each circuit board in the system. All of the processors are inter-
connected via a communications bus (Com Bus).
Broadlinx Web Page Monitoring
Broadlinx uses HTTP (Hypertext Transfer Protocol) web pages to
deliver detailed system information through the network to a PC with
Microsoft Internet Explorer 5.0 or newer (Internet Explorer 6 or newer
is recommended for best performance).
Typical aspects that can be monitored as “warnings” or alarms are all
the voltages on each circuit board, input signal presence, and output
reclocking status. Also, information on the current version of firmware
that is being used is available.
For more information, see Broadlinx / Internet Explorer Monitoring on
page 166.
SNMP/NetCentral Monitoring
When enabled, the Trinix SNMP (Simple Network Management Pro-
tocol) Agent allows the Grass Valley NetCentral application to monitor
the following:
Ta b l e 1.
Item Description
System Broadlinx board IP Address and frame
type.
Fans Fan names and status
Board Master Status of input, output, and cros-
spoint boards
Signal Master Status of input and output signals
present on frame
Reference Status of reference signal(s) presented to
the Broadlinx board
Power AC and DC status of each power supply
Thermal Master Frame temperature status
