Troubleshooting
212 Planning and Installation Manual
Input boards - SI-33110 SD and HI-33110 HD
Part side
Matrix board - DM-33100
Part side
Ref Display Meaning
ALARM DS601 Red
Master alarm for this board. A DC supply has
failed to turn on
Off Board OK
-5VAOK DS31 Green -5 VA supply OK
Off Check -5 VA supply
IN_USE DS602 Reserved for future use
Ref Display Meaning
PALARM DS952 Red
Primary alarm for this board. A DC supply has
failed on the board or the microcontroller
Off Board OK
3V3 DS951 Green 3V3 is OK
Off Check 3V3
INUSE DS901 Yellow
1 or more crosspoints now in use on this
board
Off No crosspoints in use on this board
-3V3 DS31 Green -3V3 is OK
Off Check -3V3
DONE DS950 Green The Xilinx FPGAs are properly configured
Off FPGAs failed to configure
