Planning and Installation Manual 213
512 Matrix board - DM-33501/33502
Part side
Ref Display Meaning
IN USE A DS201_1 Yellow A crosspoint is active in XPT_A IC
Off No crosspoints are active in XPT_A IC
P2V5A OK DS204_1 Green P2V5A converter is OK (for XPT_A side)
Off P2V5A converter has failed
IN USE B DS201_2 Yellow A crosspoint is active in XPT_B IC
Off No crosspoints are active in XPT_B IC
XC DONE DS402 Green FPGAs are configured
Off FPGAs are not configured
ALARM DS401 Red One or more fault conditions exist
Off Normal operation
P2V5B OK DS204_2 Green P2V5B converter is OK (for XPT_B side)
Off P2V5B converter has failed
P5V DS901 Green Logic supply is OK
Off Logic supply has failed
PS1 OK - Green Main DC-DC Converter 1 is OK
Off Main DC-DC Converter 1 has failed
PS2 OK - Green Main DC-DC Converter 2 is OK
Off Main DC-DC Converter 2 has failed
