Troubleshooting
214 Planning and Installation Manual
Output boards - SO-33110 SD and HO-33110 HD
Part side
*Trinix 512 Output Card Used as Power Source Only - In some expanded DV-33512 systems, a single output
board will be the only board in one section of the router. This board is used to provide power to certain com-
ponents on some of the input boards. Although the INUSE light is always Off, this board should not be
removed (e.g., to swap with another output board). If the board is removed, alarm lights will appear and
some loss of Broadlinx web page browsing functionality may occur. However, the router will continue to
switch, even when the Broadlinx board is being used to control the system (as in Encore applications).
Output board - HO-33120 HD
Part side
Ref Display Meaning
INUSE DS3 Yellow
1 or more crosspoints now in use on this
board*
Off No crosspoints in use on this board
DONE DS501 Green The Xilinx FPGAs are properly configured
Off FPGAs failed to configure
+10V DS41 Green +10 V supply OK
Off Check +10 V supply
+5VA DS31 Green +5VA supply OK
Off Check +5VA supply
3.3V DS51 Green 3.3 V supply OK
Off Check 3.3 V supply
ALARM DS601 Red Master alarm for this board
Off Board OK
Ref Display Meaning
XC_DONE DS568 Green The Xilinx FPGAs are properly configured
Off FPGAs failed to configure
P5V DS901 Green +5 V supply voltage present
Off Check +5 V supply
INUSE DS3 Yellow 1 or more outputs now in use on this board*
Off No crosspoints in use on this board
