Output Monitor Reclock / Force Bypass Settings
DV-33128 and DV-33256
For these models, “Auto detect on” means the signal will be checked to
see if it is HD or SD. If HD, the signal will be reclocked. If the signal is
SD, it will be bypassed.
NR-33000 Monitor Output switches “Bypass B” S3-7 and “Bypass A”
S3-8 select “auto detect on” or “force bypass” for the Monitor outputs.
“Auto Detect” (“ON”) is the default setting. DIP switch S3 is shown on
page 119.
– If the NR board is in the Primary slot, S3-8 (labelled “A”)
applies to Monitor Output 1; S3-7 (labelled “B”) applies to
Monitor Output 2.
DV-33128 (128 X 128) DV-33256 (256 X 256)
Monitor
Switch
Output Number
and Address
Monitor
Switch
Output Number
and Address
1234 1234
128 129* 130* 131* 132* 256 257* 258* 259* 260*
256 257* 258* 259* 260* 512 513* 514* 515* 516*
384 385* 386* 387* 388* 768 769* 770* 771* 772*
512 513* 514* 515* 516* 1024 1025* 1026* 1027* 1028*
DV-33512 (512 X 512)
Monitor
Switch
Output Number
and Address
1234
512 513* 514* 515* 516*
1024 1025* 1026* 1027* 1028*
1536 1537* 1538* 1539* 1540*
2048 2049* 2050* 2051* 2052*
*For Jupiter-controlled (0-based) systems, subtract one (1) from these numbers.
