Output Monitoring
Planning and Installation Manual 143
– If the NR board is in the Secondary slot, S3-8 (labelled “A”)
applies to Monitor Output 3; S3-7 (labelled “B”) applies to
Monitor Output 4.
SR-33000 Monitor Output switches “Bypass B” S2-7 and “Bypass A”
S2-8 select “auto detect on” or “force bypass” for the Monitor outputs.
“Auto Detect” (“CLOSED”) is the default setting. The location of DIP
switch S2 is shown on page 120.
– If the SR board is in the Primary slot, S2-8 (labelled “A”)
applies to Monitor Output 1; S2-7 (labelled “B”) applies to
Monitor Output 2.
– If the SR board is in the Secondary slot, S2-8 (labelled “A”)
applies to Monitor Output 3; S2-7 (labelled “B”) applies to
Monitor Output 4.
DV-33512
For this model, “Auto detect on” means the signal (both HD and SD
types) will be reclocked if possible. If the signal is not within reclocking
limits, it will be bypassed.
SR-33500 Monitor Output switches S101 and S102 select “auto detect
on” or “force bypass” for the four Monitor outputs. “Auto detect on”
(switch ON) is the default setting. See Table 27. (The location of DIP
switches S101 and S102 is shown on page 121.)
Table 27. SR-33500 Reclock/Bypass Settings for Monitor Outputs.
Monitor 1
S101-7
Monitor 2
S101-8
Monitor 3
S102-7
Monitor 4
S102-8
Auto detect ON ON ON ON ON
Force bypass
(do not reclock)
OFF OFF OFF OFF
