Planning Guide
34 Planning and Installation Manual
Figure 7. Signal flow and power supply system for DV-33512 router.
Inputs
1-128
Outputs
1-128
Outputs
129-256
Inputs
385-512
Inputs
129-256
Outputs
385-512
Outputs
257-384
Inputs
257-384
PS A
PS B
PS C
PS D
Primary Supplies
Input/Output
boards
Input/Output
boards
DM-33501/2
Matrix boards
Powered by
PS C and PS D
Powered by
PS A and PS B
