GRASS VALLEY Trinix User Manual

Duplication and Expansion
Planning and Installation Manual 53
Figure 22. 1024 x 2048 system.
513 - 1024
Inputs expanded to 1024
Outputs expanded to 2048
1 - 512
1 - 512
1 - 512
1 - 512
513 - 1024
513 - 1024
1 - 512
1 - 512
Inputs
Inputs
Dual outputs
Trinix
512 x 512
Trinix
512 x 512
Trinix
512 x 512
Trinix
512 x 512
64
PE-33008
used as
1 x 4
splitters
64
PE-33008
used as
1 x 4
splitters
32
PE-33016
used as
combiners
Dual outputs
32
PE-33016
used as
combiners
Frame 0
Frame 2
Frame 8
Frame 10
1537 - 2048
1025 - 1536
Dual outputs
Trinix
512 x 512
Trinix
512 x 512
Trinix
512 x 512
Trinix
512 x 512
32
PE-33016
used as
combiners
Dual outputs
32
PE-33016
used as
combiners
Frame 1
Frame 3
Frame 9
Frame 11
513 - 1024
513 - 1024
513 - 1024
