GRASS VALLEY Trinix User Manual

Installation
96 Planning and Installation Manual
Figure 39. Installation of rack spacers (when needed).
INSTALL RACK SPACERS ONLY
WHEN MOUNTING HOLES ARE
RECESSED MORE THAN 0.6 INCH
(15.2 MM) FROM FRONT SURFACE
OF RACK (DIMENSION ). SPACERS
WILL POSITION SWITCHER CHASSIS
SO THAT ACCESS DOOR CAN BE
OPENED FAR ENOUGH TO PERMIT
REMOVAL OF RIGHT-HAND
COMPONENTS. EACH SPACER IS
SECURED WITH 2 RACK SCREWS
(SUPPLIED).
DV-33256 CHASSIS
RACK SPACERS FOR
(KIT NO. 44-052990-001)
RACK SPACERS FOR
DV-33128 CHASSIS
(KIT NO. 44-052989-001)
DV-33512 CHASSIS/
RACK SPACERS FOR
POWER SUPPLY NOT
SHOWN. (KIT NO.
650-4352-00)
